Product Features:
◆ Easy installation, high mobility and efficient operation.
◆ Multifunctional with quick attachment changeover.
◆ Minimal site disturbance.|
Model |
Unit |
RH00724 |
RH00730 |
RH00736 |
RH00748 |
|
Overall Length |
mm |
1632 |
1784 |
1952 |
2292 |
|
Overall Width |
mm |
1350 |
1350 |
1350 |
1350 |
|
Overall Height |
mm |
720 |
720 |
720 |
720 |
|
Trench Depth |
mm |
600 |
760 |
915 |
1220 |
|
Recommended Trenching Angle |
degree |
65° |
65° |
65° |
65° |
|
Spoil Discharge Reach |
mm |
600 |
600 |
600 |
600 |
|
Rated Pressure Range |
MPa |
14-22 |
14-22 |
14-22 |
14-22 |
|
Rated Flow Range |
lpm |
80-110 |
80-110 |
80-110 |
80-110 |
|
Overall Weight |
kg |
459 |
502 |
545 |
590 |
