Product Features：
♦ Adopt high-grade Swedish Hardox 500 steel, known for its excellent combination of lightness and superior wear resistance.
♦ The pins are constructed from 42CrMo alloy steel, delivering exceptional strength and durability for reliable performance.
♦ Swiss-imported rotary motor, ensuring smooth and precise rotational movement.
♦ The cylinder is equipped with honed pipes and imported HALLITE seals, guaranteeing extended service life and leak-proof operation.
♦ The cutting blocks are made of specialized wear-resistant alloy steel, designed to withstand high temperatures and resist deformation.|
Item |
Unit |
Mini Type |
Hinge Type |
Reverted Type |
Rotary Type |
Rotating Powerful Type |
||||
|
Model |
/ |
VTH80M |
VTH180D |
VTH280D |
VTH380D |
VTH280C |
VTH180X |
VTH280X |
VTH380X |
VTH280E |
|
Suitable Excavator |
Ton |
4-8 |
9-16 |
18-30 |
32-40 |
18-30 |
9-16 |
18-30 |
32-40 |
18-30 |
|
Weight |
Kg |
400 |
800 |
1600 |
2100 |
1600 |
1100 |
1900 |
2500 |
1600 |
|
Opening |
mm |
410 |
570 |
810 |
910 |
880 |
570 |
810 |
910 |
880 |
|
Blade Length |
mm |
130 |
130 |
230 |
230 |
170 |
130 |
230 |
230 |
170 |
|
Height |
mm |
1310 |
1520 |
2320 |
2420 |
2440 |
1820 |
2650 |
2760 |
2440 |
|
Width |
mm |
388 |
600 |
700 |
800 |
500 |
600 |
700 |
800 |
500 |
|
Crushing Force |
ton |
40 |
65 |
95 |
120 |
95 |
65 |
95 |
120 |
95 |
|
Rated Pressure |
bar |
260 |
280 |
300 |
320 |
300 |
280 |
300 |
320 |
300 |
|
Rated Flow |
lpm |
140-160 |
180-200 |
220-260 |
220-280 |
220-260 |
180-200 |
220-260 |
220-280 |
220-260 |
|
Working Pressure |
bar |
240 |
260 |
280 |
300 |
280 |
260 |
280 |
300 |
180 |
|
Rotating Motor Pressure |
bar |
﹣ |
﹣ |
﹣ |
﹣ |
﹣ |
90 |
120 |
120 |
120 |
|
Rotating Motor Flow |
lpm |
﹣ |
﹣ |
﹣ |
﹣ |
﹣ |
30-50 |
40-60 |
45-70 |
40-60 |
